CUTMASTER A40
SERVICE 5-2 Manual 0-4978
5.02 Maintenance Schedule
NOTE
The actual frequency of maintenance may
need to be adjusted according to the operating
environment.
Daily Operational Checks or Every Six Cutting
Hours:
1. Check torch consumable parts, replace if
damaged, worn or when cut performance
has diminished.
2. Check plasma and secondary supply and
pressure.
3. Purge plasma gas line to remove any mois-
ture build-up.
Weekly or Every 30 Cutting Hours:
1. Check fan for proper operation and ad-
equate air ow.
2. Inspect torch for any cracks or exposed
wires, replace if necessary.
3. Inspect input power cable for damage or
exposed wires, replace if necessary.
Six Months or Every 720 Cutting Hours:
1. Check the in-line air lter(s), clean or re-
place as required.
2. Check cables and hoses for leaks or cracks,
replace if necessary.
3. Check all contactor points for severe arcing
or pits, replace if necessary.
4. Vacuum dust and dirt out of the entire ma-
chine.
CAUTION
Do not blow air into the power supply during
cleaning. Blowing air into the unit can cause
metal particles to interfere with sensitive
electrical components and cause damage to
the unit.
5.03 Common Faults
Problem - Symptom Common Cause
Insufcient
Penetration
1. Cutting speed too fast.
2. Torch tilted too much.
3. Metal too thick.
4. Worn torch parts
5.Cuttingcurrenttoolow.
6. Non - Genuine Thermal Dynamics
parts used
7. Incorrect gas pressure
Main Arc
Extinguishes
1. Cutting speed too slow.
2. Torch standoff too high from
workpiece.
3. Cutting current too high.
4. Work cable disconnected.
5.Worntorchparts.
6. Non - Genuine Thermal Dynamics
parts used
Excessive Dross
Formation
1. Cutting speed too slow.
2. Torch standoff too high from
workpiece.
3. Worn torch parts.
4. Improper cutting current.
5.Non-GenuineThermalDynamics
parts used
6. Incorrect gas pressure
Short Torch Parts Life1. Oil or moisture in air source.
2. Exceeding system capability
(materialtoothick).
3. Excessive pilot arc time
4. Gas pressure too low.
5.Improperlyassembledtorch.
6. Non - Genuine Thermal Dynamics
parts used
DifcultStarting 1. Worn torch parts.
2. Non - Genuine Thermal Dynamics
parts used.
3. Incorrect gas pressure.
