Thermo Scientific TSX Series Installation And Operation Manual

Ultra Low Temperature Freezers Appendix D: Modbus ASCII (Read Only) Parameter Table | 61
4
System Bill
of Material
Part
Number
0x03 570 2
3A 31 39
30 33 30
35 37 30
30 30 30
41 36 35
0D 0A
3A 31 39
30 33 32
34 33 31
33 35 33
35 34 34
35 32 33
30 34 31
33 30 33
31 35 32
32 30 32
30 32 30
32 30 32
30 32 30
32 30 32
30 32 30
32 30 44
30 0D 0A
155DR0A01R string All the remaining are spaces.
5 Product ID 0x03 598 2
3A 31 39
30 33 30
35 39 38
30 30 30
32 34 35
0D 0A
3A 31 39
30 33 30
34 30 30
30 31 45
32 34 30
42 39 0D
0A
0x0001E240 uint
123456 would be encoded
as 0x01E240.
6
Control
Model
0x03 59C 1
3A 31 39
30 33 30
35 39 43
30 30 30
31 34 32
0D 0A
3A 31 39
30 33 30
32 30 34
44 45 0D
0A
0x04 uchar
Note: bits b4:b1
0000: PEEK Production
Code (CNTRL 0)
0002: Variable Speed
Compressor (CNTRL 2)
0003: Single Speed and
Cascade System (CNTRL 3)
0004: Single Speed and
Single Stage System
(CNTRL 4)
0005: Single Speed and
Cascade System
(CNTRL 5).
7 Size 0x03 59D 1
3A 31 39
30 33 30
35 39 44
30 30 30
31 34 31
0D 0A
3A 31 39
30 33 30
32 30 32
45 30 0D
0A
0x02 uchar
5 units sizes
0 - 300,
1- 400,
2 - 500,
3 - 600,
4 - 700.
No Parameter
Function
Code
Address
in Hex
Size
Modbus
Command
Relay
Enclosure
Response
Data
Data
Type
Remarks

Thermo Scientific TSX Series Specifications

General

Type	Laboratory Refrigerator
Cooling Type	Forced air cooling
Defrost Type	Automatic
Door Type	Solid or glass door options
Controller Type	Microprocessor
Certifications/Compliance	UL, CE
Energy Consumption	Varies by model; refer to product specification sheet
Voltage	115V
Exterior Dimensions (H x W x D)	Varies by model; refer to product specification sheet
Interior Dimensions (H x W x D)	Varies by model; refer to product specification sheet
Weight	Varies by model; refer to product specification sheet
Shelves	Adjustable shelves
Energy Efficiency	Energy Star certified models available
