Page 11 of 29 Revision 3.3 Feb 2021
ProReact EN Analogue Installation Manual
Document Ref. PACC-MAN
Technical Specications - ProReact EN Analogue End-of-line Unit
Dimensions: W100mm x D60mm x H35mm
(with gland and mounting bracket) (W4” x D2 3/8” x H1 3/8”)
Weight: 115g
Continuous Operating Temperature Range: -40°C to +125°C
Continuous Operating Humidity Range: 0% to 99% RH (ambient temperatures between -40°C to +40°C)
0% to 75% RH (ambient temperatures greater than +40°C)
Enclosure Rating: IP65
Enclosure Material: Aluminium
Figure 3. ProReact EN Analogue End-of-line Unit Dimensional Drawing
