Thermocable ProReact EN Analogue - Technical Specifications: Sensor Cable Variants

Page 12 of 29 Revision 3.3 Feb 2021
ProReact EN Analogue Installation Manual
Document Ref. PACC-MAN
Technical Specications - ProReact EN Analogue Sensor Cable
Sensor Cable Product
ProReact EN Analogue PVC
Coated Sensor Cable
ProReact EN Analogue
Nylon Coated Sensor Cable
ProReact EN Analogue PVC and
Stainless Steel braided Sensor Cable
VdS EN54-22 Approved
(Certicate No. G220006)
3 3 3
UL 521 Listed
(File No. S8976)
3 3 ✗
VdS Model No.
ProReact EN Analogue PVC
Coated Sensor Cable
ProReact EN Analogue
Nylon Coated Sensor Cable
ProReact EN Analogue PVC and
Stainless Steel braided Sensor Cable
UL Model No.
ProReact EN Analogue Heat
Detection Cable (1) (p/n
F3050)
ProReact EN Analogue Heat
Detection Cable with nylon
outer jacket (1) (p/n F3051)
–
Thermocable Part No. F3050 F3051 F3052
Description
ProReact EN Analogue
Sensor cable with PVC outer
coat
ProReact EN Analogue
Sensor cable with additional
Nylon coating
ProReact EN Analogue Sensor Cable
with additional Stainless Steel braid
over PVC outer jacket
Construction Overall insulated, 4-core twisted with 100% coverage foil-shield and shield dump wire
Final Insulation PVC Nylon
Stainless Steel braid (min. 70%
coverage)
Wire Overall Diameter 4.83mm (0.190 in) 6.00mm (0.235 in) 5.33mm (0.210 in)
Weight (kg per km) 25.6 36.3 39.3
Colour Red Black Silver
Minimum Bend Radius 60mm (2.36 in) 100mm (4 in) 75mm (3 in)
Maximum Ambient Temperature Dependent upon Alarm Temperature (see Table 3)
Minimum Ambient Temperature -40 °C
Maximum Recoverable Temperature +125 °C
Continuous Operating Humidity
Range
0% to 99% RH (ambient temperatures between -40°C to +40°C)
0% to 75% RH (ambient temperatures greater than +40°C)
Minimum Zone Length
50m / 164ft (Class A1I/A2I and 54 °C alarm settings)
30m / 100ft (all other alarm settings)
Maximum Zone Length 500m / 1640ft (all alarm settings)
EN54-22 Environmental Group II
White core resistance per mtr Approx 17 Ω/m
Red core resistance per mtr Approx 3.3 Ω/m
Clear core resistance per mtr (each) Approx 0.1 Ω/m
Features
Hard PVC outer coating
suitable for indoor and
outdoor use. Not suitable for
use in direct sunlight and/or
exposed to harsh chemicals
Hard Nylon outer jacket.
UV stable for indoor and
outdoor use in direct
sunlight. Excellent resistance
to hydrocarbons
Stainless Steel braid for increased
mechanical toughness and abrasion
resistance. Suitable for indoor/outdoor
use with limited exposure to direct
sunlight and not exposed to harsh
chemicals
Chemical Resistance
These ratings are given as a guide and for constant, complete exposure to the chemicals listed
Shown at normal (10 to 30 deg C)temperatures. (* - not recommended, ***** - little or no impact)
Ammonia, Liquid / Gas
OOOOO OOO OOOO
Ammonia Nitrate
OOOO O OOOOO
Butane
OOO OOOOO OOOOO
Copper Nitrate
OOOOO O OOOOO
Fuel Oils
OOOOO OOOOO OOOOO
Gasoline
OOO OOOOO OOOOO
Hydrouoric Acid
OOO O O
Methyl Ethyl Ketone
O OOOOO OOOOO
Diesel Fuel
OOOOO OOOOO OOOOO
Ethyl Alcohol
OOO OOOOO OOOOO
Ethanol
OOO OOOOO OOOOO
