Page 13 of 29 Revision 3.3 Feb 2021
ProReact EN Analogue Installation Manual
Document Ref. PACC-MAN
Technical Specications - ProReact EN Analogue Sensor Cable (cont.)
Figure 4a. ProReact EN Analogue PVC Coated Sensor Cable
Figure 4b. ProReact EN Analogue Nylon Coated Sensor Cable
Figure 4c. ProReact EN Analogue PVC and Stainless Steel braided Sensor Cable
4.83mm
(0.190")
4.83mm
(0.190")
6.00mm
(0.235")
5.33mm
(0.210")
