Output cycle (external Winddisplay LED)
The telegrams „True Wind“ and „Relative Wind“ are issued every second. With baud rates
less than 4800Bd, it may be impossible to terminate output within one second, owing to
circumstances. The subsequent telegram is started upon complete output of the previous
telegram.
6.2.3 Connection Analog Inputs
• For external measurement transducers for recordation of relative humidity and
temperature with the following parameters:
Parameter
Measuring
range
Input range
Pin designation
Rel. humidity
0 … 100%
0 … 1V
CH3+ , CH3-
Temperature
-40 …+60°C
4-conductor circuit
+I , +U , -U , -I
Des.
Clamp connector: input
(Rel. humidity)
Des.
Clamp connector: temp.
(Temperature)
CH1+ ------------ +I
Pt100
in 4- conductor circuit
CH1- ------------ +U
CH2+
------------
-U
CH2- ------------ -I
CH3+ 0 ... 1V
CH3- 0 ... 1V
Note:
The barometric air pressure is recorded by the integrated Baro transmitter on the analog
interface.
Calculation of parameters for NACOS and CUSTOMER telegrams
Atmospheric pressure
Humidity
Temperature
in bar Rel. humidity in % Temperature in °C
in inch of mercury Absolute humidity in g/m
3
Dew point in °C
