13 Technical Specifications
Description
Wind transmitter inputs
Wind direction
Input
Thies Seriell Synchron
Type
Compact 4.3129.00.000 / 4.3129.60.000
Classic 4.3125.x2.100 / 101
Classic 4.3336.x1.00x / 4.3336.x2.00x
First Class 4.3150.x0.000
Sampling rate
10Hz
Wind velocity
Input
Frequency
Level (Ua)
Ua ≤ 1 V , Ua ≥3.3V
Frequency (max)
Compact 1000Hz
Classic 1550Hz
Classic 850Hz
First Class 1600Hz
Type
Compact 4.3519.00.000
Classic
4.3303.22.000/007/008/018/4.3336.x1.00x
4.3336.x2.00x
First-Class 4.3351.x0.000
Sampling rate
1Hz
Wind transmitter power
supply
Vcc WR / WG
5.1 ... 5.7V
Icc max
60mA
Interfaces
Digital interfaces
6 serial interfaces (EN 61162-1)
Type
RS422 (RS485)
Data format
Input
(3 * RS422) 8N1 (COM1 : also 7E1, parity bit is
disregarded
Receipt of the NMEA telegrams VBW, VHW,
VTG, HDT and DDC (see chapter 8)
Baud rate
1200, 2400, 4800, 9600 Bd
Analogue inputs
Only with model
4.3251.0x.002
Rel. humidity
Input
0 ... 1V (= 0 ... 100% rel. humidity)
Resolution
10bit
Precision
± 0,1%
Temperature
Input
Pt 100 (-40 ... 60°C)
Resolution
12bit
Precision
±0,2K
Integr. Pressure sensor
Only with model
4.3251.0x.002
Barometr. air pressure
Measuring range
750 ... 1100hPa
Resolution
0.1hPa
Precision
±1.5hPa @ 25°C
