© Adolf Thies GmbH & Co. KG · Hauptstraße 76 · 37083 Göttingen · Germany 021408/04/21
Phone +49 551 79001-0 · Fax +49 551 79001-65 · info@thiesclima.com ·www.thiesclima.com Page 32 of 33
MODE
MODE 0
Adjustment of brightness
1
:
The brightness of the LED display is dimmed in 18 steps via
buttons & .
Adjustment of MAX and MIN brightness:
The previously set brightness can respectively be stored as MAX or MIN
value via simultaneous actuation of buttons ▲ or ▼ and the „Enter” button.
Retrieval of MAX and MIN brightness:
The stored brightness values are retrieved by pressing buttons ▲ or ▼ for 3
seconds.
MODE 1
Adjustment of the wind velocity dimension:
The wind velocity dimension (km/h, m/s, kn and Beaufort) is set by means of
buttons &
MODE 2
Adjustment of the wind display:
The display of REL or TRUE Wind is set via buttons &
MODE 3 Activation of the wind (rel/true) remote control for external wind
display(s)
The remote control is activated or deactivated via buttons &
Following signs are additionally shown in the WT-display (minus flashes):
3−0 Remote control ON
2
3−1 Remote control OFF
MODE 4
Adjustment of the wind reference for the Winddisplay and ext.
Winddisplay(s)
The wind reference of the True Wind of the Winddisplay(s) is adjusted via
buttons &
Following signs are additionally shown in the WT-display (minus flashes):
4−0 Reference to the ship’s axis
2
4−1 Reference to geographic
North
MODE 5
Telegram filter adjustment
The respective telegram filter for the NMEA protocols is selected via
buttons &
Following signs are additionally shown in the WT-display (minus flashes):
5−0 3-digit filter mask
2
5−1 5-digit filter mask
$xxMMM.... e.g. $xxVBW $MMMMM....... e.g. $VDVBW
MODE 6 Setting of the COM1 (RS422 / RS485)
Through the buttons & the interface function is set.
6–0 :COM1 = RS422 (full-duplex) standard
6–1
:COM1 = RS485 (half-duplex). Requiring the VDT-tel. from Ultrasonic
MODE 7
Setting function of clamp connector
Through buttons & function of the clamp connector „Res.“ is set.
7– 0 :INFO & RESET
7– 1
:Entering course of the ship
