Chapter7.Locations
Thischapterintroducesthelocationsofthehardwarecomponentsonyourcomputer.
Locatingcomputercontrols,connectors,andindicators
Thistopicintroducesthelocationsofthecomputercontrols,connectors,andindicators.
Frontview
1
1
2
5678
9
11 10
12
3
4
1Microphones
2Camera
3Powerbutton
4LenovoOneLinkconnector
5acpowerconnector
6USB2.0connector
7Opticaldriveoroptical-drivebaybezel
8Audioconnector
9System-statusindicator
1
10Fingerprintreader(availableonsomemodels)
11Trackpad
12TrackPoint
®
buttons(availableonsomemodels)
1
:Forthedescriptionofthesystem-statusindicator,seeChapter5“Statusindicators”onpage49
.
©CopyrightLenovo2014,2015
53
