ThinkPad E550 - Replacing the Optical Drive or Bezel

Wheninstalling:Attachthesmallbottomcoverasshowninthefollowingillustration.
1050Opticaldriveoroptical-drivebaybezel
Foraccess,removetheseFRUsinorder:
•“1020Batterypack”onpage66
•“1030Largebottomcover”onpage67
Removalstepsoftheopticaldriveoroptical-drivebaybezel
1
StepScrew(quantity)Color
Torque
1
M2×4mm,wafer-head,nylon-coated(1)Silver
0.181Nm
(1.85kgf-cm)
Chapter9.RemovingorreplacingaFRU69
