Wheninstalling:Attachthelargebottomcoverasshowninthefollowingillustration.
1040Smallbottomcover
Foraccess,removethisFRU:
“1020Batterypack”onpage66
Removalstepsofthesmallbottomcover
Loosenthescrew1andthenremovethesmallbottomcover2.
1
2
68HardwareMaintenanceManual
