ThinkPad E550 - Rear View Component Locations; Bottom View Component Locations

Rearview
1
2
3
4
5
6
7
8
1System-statusindicator
1
2AlwaysOnUSB3.0connector
3USB3.0connector4High-DefinitionMultimediaInterface(HDMI™)
connector
5Videographicsarray(VGA)connector
6Ethernetconnector
7Fanlouvers
8Security-lockslot
1
:Forthedescriptionofthesystem-statusindicator,seeChapter5“Statusindicators”onpage49.
Bottomview
2
1
3
2
4
5
1Smallbottomcover
2Batterylatches
3Batterypack4Mediacardslot
5Largebottomcover
LocatingFRUsandCRUs
Thistopicintroducesthefollowingserviceparts:
•“MajorFRUsandCRUs”onpage56
