•“1040Smallbottomcover”onpage68
•“1050Opticaldriveoroptical-drivebaybezel”onpage69
•“1070Harddiskdriveassemblyorsolid-statedriveassembly”onpage70
•“1080WirelessLANcard”onpage72
•“1090Coin-cellbattery”onpage73
•“1110Keyboard”onpage73
•“1120Keyboardbezelassembly”onpage75
•“1130Systemboardandthermalfan”onpage78
•“1140dc-in/USB-connectorboardwithcable”onpage83
RemovalstepsoftheLCDunit
Note:Thecomputerthatyouareservicingmightbedifferentfromtheoneinthefollowingillustrations.
Instep1,releasethewirelessantennacablesfromthecableguides.
1 1
1
1
1
1
1
1
1
