2
1
StepScrew(quantity)Color
Torque
2
M2×3mm,wafer-head,nylon-coated(1)
Black0.181Nm
(1.85kgf-cm)
3
Wheninstalling:Plugtheredcableintothemainconnector,andthebluecableintotheauxiliaryconnector.
RemovalstepsofmSATAsolid-statedrive
ThecomputercomeswitheitheraPCIExpressMiniCardforwirelessWANoranmSATAsolid-statedrive.If
thecomputerisequippedwithanmSATAsolid-statedrive,itisinstalledinthewirelessWANcardslot.
Attention:
Donotdropthedriveorapplyanyphysicalshocktoit.Thedriveissensitivetophysicalshock.Improper
handlingcancausedamageandpermanentlossofdata.
Beforeremovingthedrive,havetheusermakeabackupcopyofalltheinformationonitifpossible.
Neverremovethedrivewhilethesystemisoperatingorisinsuspendmode.
Chapter9.RemovingorreplacingaFRU63
