Installing the product
13
3
2
1
➊➊
➋➋
Remove the protective film from the adhesive mount,
and then press the mount to the heat blocking film.
Push the mount against the windshield to ensure
that the mount is firmly fixed.
4
Align the product to the mount, and then slide it into
the locking position until you hear a click.
• The product may fall and be damaged during
vehicle operation if it is not firmly fixed to the
mount.
• If you need to remove the mount from the
windshield to alter the installation location, be
careful not to damage the windshield’s film coat.
5
Set the vertical angle of the camera appropriately.
To confirm the camera angle, record a video after installation and check the video using the mobile
viewer or the PC viewer. If necessary, adjust the camera angle again. For more information about the
mobile viewer or the PC viewer, refer to "4. Using the mobile viewer" on page 24 or "6. Using the PC
viewer" on page 26.
