2 CONTROLS
2. 11 BOOM SUPPORT
For safety while performing regular service or
maintenance work, the loader is equipped with boom
support pins. The boom support pins, when extended,
prevent the boom arms from dropping if hydraulic
pressure is relieved or the foot control pedals accidentally
cycled.
To operate the boom support, first remove any bucket or
attachment from the quick-tach; raise the boom arms to
full height; push the two boom lock pin handles (Fig. 2.
11A), located directly in front of the operator at the top of
the operator compartment, outward, extending the boom
support pins (See Fig. 2. 11B). Slowly lower the boom
arms down onto the pins. To retract the support pins, first
lift the boom arms off of the pins before retracting.
Safe Shutdown Procedures
-
Stop machine
- Lower the bucket and other attachments flat on the
ground.
- Position controls in neutral.
- Engage parking brake.
- Idle engine for short cool-down period.
- Stop engine.
- Cycle hydraulic controls to eliminate pressure.
- Raise operator seat bar.
- Check that controls are locked in neutral.
- Unbuckle seat belt.
- Remove ignition key and lock covers and closures.
Don’t give anyone the key to an accident.
C - 361
C - 362
C729
Fig. 2.11B
Fully retract the boom
supports before raising
or lowering boom arms.
IMPORTANT
C730
Fig. 2.11A
