THOMSON easytv 32HD2S13 - TV Buttons and Connections

7
Your TV is also prepared for a VESA-compliant wall mount bracket. If it is not supplied with your TV, contact your
local dealer to purchase the recommended wall mount bracket.
Holes and measurements for wall mount bracket installation:
W (mm) H (mm) D (mm) L (mm)
24” 100 100 4 (M4) 6
32” 100 100 6 (M6) 8
40” 200 200 6 (M6) 8
43” 200 200 6 (M6) 8
3. TV buttons and connections
Caution:
If you want to connect a device to the TV, make sure that both the TV and the device are turned o
before making any connection. After the connection is done, you can turn on the units and use them.
Do not touch or be close to the HDMI, USB terminals, and prevent electrostatic discharge to
disturb these terminals while in USB operation mode, or it will cause the TV to stop working or
abnormal status.
Note:
The actual position and arrangement of ports may be dierent from model to model.
3.1. TV Button
Press this button in standby mode to turn on / o the TV
W
H
L
D
