MEC 2 MICROPROCESSOR ENGINE/GENERATOR CONTROLLER
PM056 Rev 6 05/10/15 Thomson Technology
38
and the current time remaining in the countdown sequence. When the timing
function has expired, the LCD display will automatically change to either the next
timing sequence countdown display or return to the original system status menu.
LCD DISPLAY
ENGINE START
DELAY
45 SEC
Displays specific time delay function currently in operation
Displays current time in seconds or minutes that are left in the specific timing
sequence.
NOTE:
During a timer countdown sequence, a different
display screen may be selected by pressing the
ENTER pushbutton.
The following timer countdown screens are provided:
ENG START DELAY XX SEC.
CRANK PERIOD XX SEC.
REST PERIOD XX SEC.
STARTER RE-ENGAGE DELAY XX SEC.
BYPASS DELAY XX SEC.
COOLDOWN DELAY XXXX SEC.
WARMUP DELAY* XX SEC.
RETURN DELAY* XXX SEC.
NEUTRAL DELAY* XX SEC.
*Countdown screens only appear if Utility/Gen Read To Load outputs are
programmed.
8.2.4. GENERATOR AC METERING
Four generator AC metering screens are provided as described below.
8.2.4.1.AVERAGE VOLTAGE/CURRENT & FREQUENCY DISPLAY
The generator average voltage/current & frequency metering screen
allows the operator to simultaneously view all the listed parameters.
