MEC 2 MICROPROCESSOR ENGINE/GENERATOR CONTROLLER
PM056 Rev 6 05/10/15 Thomson Technology
39
LCD DISPLAY
Vavg

Aavg

Freq

600 432 60.1

Displays the average generator voltage as follows:
3-phase system: AVERAGE LINE TO LINE VOLTAGE--Phases
AB,BC,CA
1-phase system: LINE TO LINE VOLTAGE--Phases A to B

Displays the average generator current as follows:
3-phase system: AVERAGE LINE CURRENT--Phases A,B,C
1-phase system: AVERAGE LINE CURRENT--Phases A,B

Displays generator frequency in hertz (HZ). The frequency is displayed
with a resolution of 1/10 of a hertz.
8.2.4.2.GENERATOR KVA DISPLAY
The generator’s total power output in kilo-voltamperes (KVA) is displayed.
LCD DISPLAY
KVA
532.31
8.2.4.3.GENERATOR PHASE VOLTAGE DISPLAY (LINE TO LINE)
The generator phase voltage screen allows the operator to view the
generator AC voltage on all 3 phases (or single phase system as
selected).
LCD DISPLAY
Vab

Vbc

Vca

600 600 600
