THOMSON MEC 2 - V1.4 - Page 45

MEC 2 MICROPROCESSOR ENGINE/GENERATOR CONTROLLER
PM056 Rev 6 05/10/15 Thomson Technology
40

Displays generator voltage as follows:
3-phase system: LINE TO LINE VOLTAGE--Phases A to B
1-phase system: LINE TO LINE VOLTAGE--Phases A to B

Displays generator voltage as follows:
3-phase system: LINE TO LINE VOLTAGE--Phases B to C
1-phase system: LINE TO NEUTRAL VOLTAGE--Phases A-N

Displays generator voltage as follows:
3-phase system: LINE TO LINE VOLTAGE--Phases C-A
1-phase system: LINE TO NEUTRAL VOLTAGE--Phases B-N
8.2.4.4. GENERATOR PHASE/NEUTRAL VOLTAGE DISPLAY (LINE
TO NEUTRAL)
The generator phase/neutral display allows the operator to view the
generator line to neutral voltage for all 3 phases of the system. Note:
The generators neutral must be connected to MEC 2 terminal TB1-VN
and the “neutral connected” prompt in the main program menu must be
selected as “Yes”.
LCD DISPLAY
Van

Vbn

Vcn

347 347 347

Displays generator voltage Phase A to Neutral.

Displays generator voltage Phase B to Neutral.

Displays generator voltage Phase C to Neutral.
8.2.4.5.GENERATOR PHASE CURRENT DISPLAY
The generator phase current screen allows the operator to view the
generator load current on all 3 phases (or single phase system as
selected).
LCD DISPLAY
Amps a

b

c

408 451 415
