MEC 2 MICROPROCESSOR ENGINE/GENERATOR CONTROLLER
PM056 Rev 6 05/10/15 Thomson Technology
41
Displays generator load current as follows:
3-phase system: PHASE A CURRENT
1-phase system: PHASE A CURRENT
Displays generator load current as follows:
3-phase system: PHASE B CURRENT
1-phase system: PHASE B CURRENT
Displays generator load current as follows:
3-phase system: PHASE C CURRENT
1-phase system: not applicable
8.2.4.6.GENERATOR FREQUENCY/HOURMETER DISPLAY
The generator frequency and operating hours are displayed
simultaneously on this screen.
LCD DISPLAY
FREQ 60.1Hz
HOURS 56783 Hrs
Displays generator frequency in hertz (HZ). The frequency is
displayed with a resolution of 1/10 of a hertz.
Displays unit operating hours
8.2.5. ENGINE PARAMETER DISPLAY
Two engine operating parameter screens are provided as described below.
8.2.5.1.BATTERY VOLTAGE/ENGINE SPEED (tachometer)
The battery voltage and engine speed are displayed simultaneously on
this screen.
LCD DISPLAY
BATTERY 27.0Vdc
SPEED 1800rpm
