MEC 2 MICROPROCESSOR ENGINE/GENERATOR CONTROLLER
PM056 Rev 6 05/10/15 Thomson Technology
42
Displays battery voltage in DC volts. The voltage is displayed
with a resolution of 1/10 of a volt.
Displays engine speed in revolutions per minute (RPM).
8.2.5.2.ENGINE TEMPERATURE/OIL PRESSURE
The engines operating temperature and oil pressure are displayed
simultaneously on this screen.
LCD DISPLAY
ENG TEMP 57 Deg C
OIL PRESS 200 KPA
Displays engine temperature in either degrees Celsius or
Fahrenheit (as selected).
Displays engine oil pressure in either pounds per square inch
(PSI) or in Kilopascals (KPA) (as selected).
8.2.6. PROGRAM MENU
The programming menu is used to access the MEC 2 programmable functions
such as time delays, analog fault settings, digital fault settings and calibration.
Access to the programming sub-menus may only be obtained with a security
password number. The sub menus are organized as follows:
PROGRAMMING MENU NO
YES PASSWORD
LCD DISPLAY
PROGRAM MENU?
NO
Displays two messages that may be toggled between YES and NO by
pressing the INCREMENT pushbutton. Their functions are described
as follows:
NO Programming sub-menus are disabled when NO is displayed.
YES Programming sub-menus are enabled when YES is displayed and
a valid password number is entered.
To Next Page
