THOMSON RD1000 / RD1002
Page 47
Receiver Descrambler - User Manual (release 7.3.1)
Edition 2 – October 2010
5. The cursor will now be on, “Gateway.”
6. Use the and buttons to select the column to edit
and use the and buttons to change the Gateway,
then press the button to save the selection.
MAC Address
This option will show the physical MAC Address of the MPEG/IP card.
1. Use the and buttons to move the cursor to “MAC
Address” to view the MPEG/IP card’s physical MAC
Address.
To Edit the Option Card Input Settings
To edit this input card, use the following steps:
1. Press the button.
Note: For dual units, select RDS1 or RDS2, then press .
2. Use the and buttons to select “Input Modules”, and
press the button.
3. Use the and buttons to move the cursor to the
“MPEG/IP” card of the specific slot (e.g. 1-4). Notice the
location diagram in the upper right corner of the screen
changes as the cursor moves by each card.
4. Press the button once to display the Status screen for
the MPEG/IP card.
5. Press the button again to display the Edit screen for the
MPEG/IP card.
 Input 
►MPEG/IP 1-4
QPSK 2-2
 Input 
Active Input
Backup Mode
►Input Modules
 Input 
►Active Input
Backup Mode
Input Modules
 MPEG/IP 1-4 Net 
0.0.0.0
MAC Address
► 00012ABCD123
 MPEG/IP 1-4 Net←→
255.0.0.0
Gateway
► 000.000.000.000
