THORLABS TSP01 User Manual

© 2018 Thorlabs22
TSP01
5. Be sure that the library “TLTSPB_32.dll” is either beside the application, in the
VXIPNPPATH or PATH or in the system folder. Use the same location of the
TLTSP_32.dll.
6. The TLTSPB uses a communication server ThorFrameServer.exe which can be found in
the hidden folder COMMONAPPDATA (“C:\ProgramData\Thorlabs\ThorFrame”).
4.2 WYOA for Previous-Revision Sensors
This chapter provides information on how to write your own application for previous-revision
TSP01 sensors which can be identified by the lack of a "RevB" label.
Note
For TSP01 sensors labeled "RevB", please refer to the instructions in the section 4.1. " Write
Your Own Application for TSP01 RevB Sensors ". TSP01 RevB devices run with a new driver
that does not require NI-VISA
™
.
In order to write your own application for TSP01, you need a specific instrument driver and
some tools for use in different programming environments. The driver and tools are being in-
stalled to your computer during software installation and cannot be found on the installation CD.
Note
TSP01 software and drivers are 32 bit applications. As for this reason, in 32 bit systems, they
are installed to
“C:\Program Files”
while in 64 bit systems - to
“C:\Program Files (x86)”
In the table below you will find a summary of the files needed for specific programming environ-
ments. Section 4.2.1 specifies the locations of these files.
Programming environment
Necessary files
C, C++, CVI
*.h (header file)
*.lib (static library)
C#
.net wrapper dll
Visual Studio
*.h (header file)
*.lib (static library)
or
.net wrapper dll
LabView
™
*.fp (function panel) and NI-VISA
™
instrument driver
Beside that, LabVIEW
™
driver vi's are provided with the
*.llb container file
19
