THUNDER TIGER TTR4571 User Manual

4
PARTS DRAWINGS
AS6291 FRP Fuselage
AS6293 Horizontal Tail
AS6292 Main Wing
AS6301 Decals
No.3291 Aluminum
Spinner (3-blade)
Decal(B)
Left Wing(1)
CA Hinge(6) Air Cooling Inlet(2)
Right Wing(1)
3x15mm
Wood Screw(2)
FRP Fuselage(1)
FRP Opening Cover(1)
CA Hinge(4)FRP Tube(1, S)
Rudder(1)
Al. Spinner(2-blade,1)
Back Plate(1)
FRP Tail Cover(1)
Right H.T.(1)
FRP Tube(1,L)
AS6296 Cowling
Cowling(1)
2x8mm
Washer Wood Screw(22)
Doubler(24)
CA Hinge(2)
Rubber Band(1)
Plywood Parts(A) Plywood Parts(B) Plywood Parts(C)
FRP Wing Joiner Tube(1)
Dowel(4)
Left H.T.(1)
Adaptor(1)
Spinner Bolt(1)
Bushing(1)
No.3290 Aluminum
Spinner (2-blade)
Al. Spinner(3-blade,1)
Back Plate(1)
Adaptor(1)
Spinner Bolt(1)
Bushing(1)
Decal(A)
2.3x12mm
Washer Wood Screw(6)
2.3x12mm
Washer Wood Screw(8)
3x16mm Flat Head Wood Screw(8)
Aileron Servo Case(L/1, R/1)
2x8mm
Washer Wood Screw(6)
OPTIONAL PARTS
AS6302 Plywood Parts
