Thundercomm Qualcomm Robotics RB5 - Processor, Memory, and Storage

Robotics RB5 Development Kit Hardware User Manual
Copyright© 2020 Thundercomm Technology Co., Ltd. All rights reserved.
8
3.2 Processor
QRB5165 is the new generation Qualcomm® Snapdragon™ premium-tier processor with
robotic application. It is designed with the 7 nm process, for superior performance and
power efficiency.
3.3 Memory
The QRB5165 uses a package on package (PoP) LPDDR5 RAM configuration and discrete
UFS3.0 flash memory.
 The LPDDR5 interface goes directly to the QRB5165 built-in LPDDR controller. The
maximum DDR clock is 2750MHz.
 The UFS flash memory interfaces with QRB5165 over a dedicated UFS PHY bus
supporting the UFS 3.0 specification.
3.4 MicroSD
MicroSD slot signals are routed directly to the QRB5165 SDC2 interface.
