Rev E TR-220 90 008 088-1
1-5
SECTION B
EQUIPMENT DESCRIPTION
1.5 Specifications
Transponder Transmitter
Frequency 1030 MHz ± 10 kHz
Output Power >
4dBm
Modes A, C, S, ADS B TX/RX,
and TIS
Transponder Receiver
Frequency Frequency 1086.5 to 1093.5 MHz
Accuracy ± 200 kHz
Power Range 47 to 64 dBm
Accuracy ± 2 dB (direct connect)
± 3 dB (radiated)
Sensitivity Range. -50 to -87 dBm
Accuracy ± 2 dB (direct connect)
± 3 dB (radiated)
Reply Percent Range 0 to 100%
Accuracy ± 1%
DME
DME Receiver
Frequency Frequency Channel Freq +3.5 MHz
Accuracy ± 200 kHz
Sensitivity Range < -35 dB
DME Transmitter
Frequency Frequency 962 to 1213 MHz
Accuracy ± 100 kHz
Power ≥ 4 dB
TCAS
TCAS Transmitter
Frequency 1090 MHz ± 10 kHz
Output Power >
4dB
Modes C & S
Antenna Beamwidth…. 15° Sum & Diff Ports
30° Sum only
