SECTION B
OPERATING CONTROLS, INDICATORS, AND CONNECTORS
2.5 General
This section covers location and function of the operating controls, indicators, and connectors. All
controls, indicators, and connectors are located on the front panel of the Test Set.
2.6 Controls, Indicators, and Connectors
Figure 2-2 and Table 2-2 indicates the location and the function of each item on the front panel of
the Test Set.
Controls, Indicators, and Connectors
Figure 2-2
1 2 3 4 5 6 7 8 9 10 11 12
131415 1618 17
