Rev E TR-220 90 008 088-1
2-52
2.19 RS-232 Download Procedures
The TR-220 contains memory to down load results received during the AUTOMATIC
sequence of tests to a PC thru the use of the RS-232 port located on the front panel of
the Test Set. Once downloaded, the information can be displayed in an Excel file to be
viewed and saved for future reference. The following Tests and results are captured to
the Test Set’s memory:
1. MODE A & SLS
Re: Mode A Reply, Mode A Code, MA SLS
2. MODE C
Re: Mode C Reply, Mode C Altitude
3. MODE A & SLS
MA SLS, P1 > P2, Reply, P1 = P2
4. MODE A ALL CALL
Re: Mode A & C Reply, MA and C Address
5. MODE C ALL CALL
Re: MC & A Reply, Mode A & C Address
6. MODE A ONLY
Re: Results
7. MODE C ONLY
Re: Results
8. MODE S SURVEILLANCE IDENTITY
Re: DF5 Reply, DF5 ID, DF5, Flight Status
9. MODE S SI LOCKOUT
Re: Results
10. MODE S SUVEILLANCE ALTITUDE
Re: DF4 Reply, DF4 Altitude, DF4 Flight Status
11. MODE S SURVEILLANCE SHORT
Re: DF0 Reply, DF0 Altitude, DF0 VS, Tail Number
12. MODE S COMM IDENTITY
Re: DF21 Reply, DF21 ID, DF21 Flight ID
13. MODE S COMM ALTITUDE
Re: DF20 Reply, DF20 Altitude
14. UNDESIRED REPLIES
Re: Results
15. SQUITTER
Re: ACQ Per, ACQ Address, Ext PER, Extended Address
16. DIVERSITY
Re: Results, Diversity Attenuation
17. SENSITIVITY
MA, MC, & MS Sensitivity
18. POWER AND FREQUENCY
Re: Power (in dB), Power (in Watts), and Frequency
