Rev E TR-220 90 008 088-1
2-16
9. To advance, toggle the AUTO/TEST/MANUAL switch to MANUAL. The next test
in sequence will commence.
NOTE
END OF MODE A/C MANUAL TESTS
Power, Frequency /
Testing . . .
Power, Frequency
54 dB 1090.0 MHz
Test Completed. Display indicates the UUT
power (54 dB) and Frequency (1090.0) in
MHz.
UUT Power and Frequency Test is
initialized.
Power measurements are measured in Watts or dBm. The Test Set only
displays dB due to display restrictions. To change the display to indicate
Watts, access the SETUP menu and toggle to the Power in Watts menu.
Use the UP/DOWN toggle to make a selection.
A: -73.9dB C: -73.9dB
Sens. A&C: PASS
Test Completed. Display indicates the UUT
receiver sensitivity for mode A (-73.9db)
and Mode C (-73.9dB) PASS is displayed
when Mode A/C sensitivities are within
1dB.
