23. Toggle the AUTO/TEST/MANUAL switch to MANUAL to advance to the next
sequence:
END OF MODE S MANUAL TESTS
Power, Frequency /
Testing
Power, Frequency /
54 dBm 1090.0Mhz
UUT Power and Frequency tests for modes
A and C are initiated.
Test completed. UUT transmitter power
(54dBM) (shown in dBm or WATTS as
selected in Set-up Menu) and UUT
transmitter frequency in MHz.
Mode S Width Ampl. /
Testing . . .
Rply Dlay 128.20us P
MS Jitter 50ns P
MS Ampl Var. PASS
MS Pulse Width PASS
Test Complete. Display indicates the Mode
S Reply Delay, Mode S Jitter, Mode S P6
mplitude Variation, and Mode S P6 Pulse
Width with a P(ass) or F(ail) indication for
each measurement.
**
** Denotes a test only available with
Software Revision 5.00 or
reater.
