7. Toggle the AUTO/TEST/MANUAL switch to the AUTO position to advance to
the Velocity menu. Utilize the UP/FWD-DOWN/REV switch to set the velocity to
the desired setting. The Velocity is adjustable from 120Kts to 1200Kts.
8. Toggle the AUTO/TEST/MANUAL switch to the AUTO position to advance to
the Vert Speed menu. Utilize the UP/FWD-DOWN/REV switch to set the vertical
speed to the desired setting. The Vert Speed is adjustable from +7,500 fpm. to -
7,500 fpm.
9. Toggle the AUTO/TEST/MANUAL switch to the AUTO position to advance to
the TCAS dist menu. Set the distance of the intruder to the UUT by toggling the
UP/FWD-DOWN/REV switch to the desired range. The range is adjustable from
1 nmi. to 50 nmi.
10. Toggle the AUTO/TEST/MANUAL switch to the Mode S Addr menu. The
operator may change the Mode S address of the intruder aircraft. Switching the
switch to ALT and then using the UP/FWD-DOWN/REV switch will enable the
first two digits of the address to be changed. Switching to DIST and then to
SPEED will enable the second tow digits and final two digits to be changed with
the UP-DOWN switch respectively.
By toggling the IDENT switch, the Mode S address will be decoded into the
corresponding aircraft tail number where possible, or just show the country code
for those countries that do not have an appropriate algorithm.
Vert Speed: +000 fpm
Chg:Up/Dn Cont: AUTO
TCAS dist: 5 nmi
Chg:Up/Dn Cont: AUTO
Velocity: 180 nmi/h
Chg:Up/Dn Cont: AUTO
Mode S Addr: 3D8DFF
Chg: Al/Ds/Sp-Up/Dn
Mode S Addr: 3D8DFF
DEU: D-GAAH
To Next Page
