(10,000 – 20,000) x 600
VS = ----------------------------------------------
20 x 60
Complete the equation to find the correct Vertical Speed (VS) value to be
entered.
-6,000,000
VS = --------------------------------
12000
VS = -5000
The correct Vertical Speed variable is -5000 fpm.
Table 2-5 lists random TCAS Scenarios that will result in proper intruder
convergence resulting in an RA and/or TA on the TCAS display.
Scenario
#
UUT
ALTITUDE
(Pumped Up)
STARTING
ALTITUDE
VELOCITY
TCAS
DISTANCE
VERTICAL
SPEED
1 -1000 ft. 2000 ft. 180 kts 10 nmi -900 fpm
2 -500 ft. 1000 ft. 300 kts 15 nmi -500 fpm
3 0 ft. 0 ft. 600 kts 20 nmi 0 fpm
4 500 ft. 1000 ft. 300 kts 25 nmi -100 fpm
5 1000 ft. 3500 ft. 180 kts 25 nmi -300 fpm
6 5000 ft. 4000 ft. 300 kts 25 nmi 200 fpm
7 7500 ft. 9500 ft. 600 kts 40nmi -500 fpm
8 10,000 ft. 15,000 ft. 180 kts 50 nmi -300 fpm
9 12,500 ft. 7500 ft. 300 kts 25 nmi 1000 fpm
10 15,000 ft. 30,000 ft. 600 kts 30 nmi -5000 fpm
11 17,500 ft. 34,000 ft. 180 kts 15 nmi -3300 fpm
12 20,000 ft. 10,000 ft. 300 kts 50 nmi 1000 fpm
13 25,000 ft. 41,500 ft. 600 kts 30 nmi -5500 fpm
14 33,000 ft. 50,000 ft. 180 kts 30 nmi -1700 fpm
15 42,000 ft. 15,000 ft. 300 kts 25 nmi 5400 fpm
16 49,000 ft. 31000 ft. 600 kts 45 nmi 4000 fpm
17 3000 ft. 5000 ft. 300 kts 25 nmi -400 fpm
18 3500 ft. 2000 ft. 180 kts 45 nmi -100 fpm
19 4500 ft. 2500 ft. 300 kts 50 nmi 200 fpm
20 7500 ft. 3000 ft. 600 kts 45 nmi 1000 fpm
21 8500 ft. 10,000 ft. 180 kts 15 nmi -300 fpm
22 9000 ft. 15,000 ft. 300 kts 30 nmi 1000 fpm
Additional TCAS Intruder Scenarios
Table 2-5
