7. Press the AUTO/TEST/MANUAL switch to continue. The Roll angle will be
displayed in degrees. Part of the BDS5 Track and Turn report.
8. Press AUTO/TEST/MANUAL to move to the next test. The True track angle will
displayed in degrees and the Track Angle rate will be displayed in degrees per
second. Part of the BDS5 Track and Turn report.
9. Press AUTO/TEST/MANUAL to move to the next test. The True Airspeed and
Ground Speed will be displayed in Knots. Part of the BDS5 Track and Turn
report.
10. Press AUTO/TEST/MANUAL to move to the next test. The Indicated Airspeed
will be displayed in Knots, the Heading in degrees and the Mach number. Part of
the BDS6 Heading and Speed report.
11. Press AUTO/TEST/MANUAL to move to the next test. The Barometric Altitude
Rate and Inertial Vertical Velocity will be indicated in feet per minute. Part of the
BDS6 Heading and Speed report.
12. Press AUTO/TEST/MANUAL to move to the next tests Subsequent screens will
display the values contained in registers BDS 1,0; 1,7; 1,8; and 1,9. The
decoded register values are shown in Hexadecimal.
BDS5 Roll Angle
+90 D
BDS5 True Trk Angle
An E120 D Rt + 8 D/s
BDS5 Tru ASpd 600K
Gnd Speed 550K
BDS6 Ind Aspd 600K
Hdg E120 D Mch 1.000
BDS6 Balt +6000’/M
In VertVel +6000’/M
BDS 10 Datalink
10 00 00 80 E0 00 00
To Next Page
