Use and maintenance manual TIGER 370 CNC--MR
ADJUSTING THE CURRENT
To adjust the current:
--- Position DIP B---4 to the ON position (current adjustment mode).
--- Rotate trimmer RV6 until the screen displays the current required (clockwise
to increase).
Adjustment range: from 1A to 10A step 0.5A.
--- Re t u r n D I P B --- 4 t o t h e O F F p o s i t i o n ( R U N m o d e ) .
VALUE DIS PLAYED CURRENT SET
1
1A
5 5A
5. 5.5 A
0 10 A
A 11 A
B 12 A
Adjust the current witn tne motor stopped.
DIP- SWITCHES SUMMARY TABLE
DIP SWITCH A
DIP
ON
OFF
6 Set Rate Set Rate
5 Set Rate Set Rate
4 Set Rate Set Rate
3 Set Rate Set Rate
2 Not used Not used
1 Reduction of current in stand---by mode to
50% of set current
Reduction of current in stand---by mode to
25% of set current
DIP SWITCH B
DIP
ON
OFF
4 Current adjustment mode RUN mode
3 Step division sett ing Step division setting
2 Step division sett ing Step division setting
1 Not used Not used
N.B.
