Timberwolf TW 150DHB - 35 Control Panel

TIMBERWOLF
TW 150DHB
35
CONTROL PANEL
Item Part No Part Name Q’ty
1 0236 M5 P Nyloc Nut 2
2 0911 Throttle Cable 1
3 0708 M5 C Washer 2
4 1758S Control Panel 1
5 0709 M6 C Washer 4
6 0438 M6/16 Pan Pozi 4
7 0435 M5/16 Pan Pozi 4
Item Part No Part Name Q’ty
8 1757 Amber LED 1
9 0327 Hours Counter 1
10 Supp’d with engine Ignition Switch 1
11 1756 Control Panel Decal 1
12 1397 Throttle Lever 1
13 1470 Rubber Protector 1
1
9
6
x2
x 4
2
4
5
3
8
x 2
12
7
10
0
1
2
11
12
