Timberwolf TW 150DHB - Electrical Layout

TIMBERWOLF
TW 150DHB
38
ELECTRICAL LAYOUT
Item Part No Part Name Q’ty
1 1975 Funnel Loom 1
2 1406 Safety Bar Loom 1
3 18481 Main Engine Loom 1
Item Part No Part Name Q’ty
4 1375
+
VEBattery Cable 1
5 1376
-
VEBattery Cable 1
1
2
3
4
5
