Timberwolf TW 150VTR - Belt Tensioner

TIMBERWOLF
TW 150VTR
35
Item Part No Part Name Q’ty
1 0313 M12/100 Bolt 1
2 0415 Heavy Washer 1
3 0491 Bearing 6205 2
4 0411M Pulley 1
5 0472M Pulley Boss 1
6 N/A to purchase Slider 1
7 0469MS Slider Block 1
8 1342PS End Plate 1
9 made in production Washer 1
10 0476 Plain M8 Nut 1
11 2988 M8/90 Bolt 1
Date Last Modified: 17th Aug 05
1
2
3
4
3
5
6
7
8
9
10
11
BELT TENSIONER
