Timberwolf TW 150VTR - Drive Train

TIMBERWOLF
TW 150VTR
42
DRIVE TRAIN
Item Part No Part Name Q’ty
1 1175 Rotor Pulley 1
2 18961M Key 1
3 1410 Taper Lock Bush 2517 1
4 0310 Belt SPA 1060 3
Item Part No Part Name Q’ty
5 1170M Engine Pulley 1
6 1533 Vee Belt SPA 900 1
7 2975 Taper Lock Bush 1610 18 mm 1
8 2974 Pulley 140 x 1 SPA 1
Date Last Modified: 10th Sept 09
1
2
3
4
5
6
7
8
