2.1.2 Bottom cover
The bottom cover includes a ve-pin socket, a power light & button, a Mini USB socket, a speaker, a
battery compartment, a connection screw, etc.
Figure 2-1-3 Bottom cover
Figure 2-1-4 Bottom cover
6
5
3
1
2
4
