User Manual - Network Speed Dome - WϭϭϬϯϮͲd

17
SD Card Slot
Figure 2-24 SD Card Slot
3. Secure the bracket with 4 hex nuts and washers.
Figure
2-25 Secure the Bracket
4. Apply thread tape to the thread of the head cover and rotate the head cover to the
bracket. Secure the head cover to the bracket with set screws (supplied).
Figure
2-26 Secure the Head Cover
5. Buckle the handle to the safety rope.
