User Manual - Network Speed Dome - WϭϭϬϯϮͲd

13
Pendant Adapter
Lock Screw
Figure
2-16 Pendent Adapter
2.1.3 Type III Speed Dome
Steps:
1. Remove the protective sticker as shown in Figure 2-17.
Protective Sticker
Figure
2-17 Remove Protective Sticker
2. Remove the cover on the back of the speed dome as shown in Figure 2-18. Insert
the
SD card to the SD card slot and install the cover back.
