User Manual - Network Speed Dome - WϭϭϬϯϮͲd

16
Pendant Adapter
Lock Screw
Figure
2-22 Pendent Adapter
2.1.4 Type IV Speed Dome
Steps:
1. Remove the protective sticker as shown in Figure 2-23.
Protective Sticker
Figure 2-23 Remove Protective Sticker
2. Remove the cover on the back of the speed dome. Insert the SD card to the SD card
slot and install the cover back.
