User Manual - Network Speed Dome - WϭϭϬϯϮͲd

1
1 Overview
Please turn the power off before connect the cables.
The overview of different speed domes can be categorized into four types, refer to the
content below for the details.
The cables are distinguished by different colors. The labels attached on the cables are for
identification.
Type I refers to the 5-inch speed dome.
Type II refers to the 6.5-inch speed dome.
Type III refers to the 7-inch IR speed dome and7-inch laser speed dome.
Type IV refers to the 8-inch IR speed dome and 8-inch laser speed dome.
The figures below are for reference only, please refer to the actual product as the
standard.
1.1 Overview of Type I Speed Dome
RED
AC
2
4
V
YEL
L
O
W/
G
REEN
B
LACK
AC
24
V
1
2
3
4
5
6
7
8
Figure
1-1 Cable Interface of Type I Speed Dome
