Compact IP Codec User's Manual
30
Techno Mathematical Co., Ltd.
2140P
Figure 5-10 Encoder – Connect Setting
■ Start up ENCODER.
■ On the Connect Setting tab, select the
location in the [Specified Decoder
Connection] list where you want to add a
decoder, and then click [Edit].
Figure 5-11 Encoder – Add Decoder
■ Enter the information of the
transmission destination decoder and
then click [OK].
*Remarks can be left blank.
Figure 5-12 Encoder – Connect Status
Selecting a [Connect State] check box
causes the stream to be transmitted to
that decoder.
Leaving a check box selected
automatically transmits the stream to
that decoder when power is turned on.
Initial default settings are shown in the table below.
Table 5-6 Encoder – Specified Decoder Connection – Initial Default Setting
Connect State IP Port Remark
(Not selected) 192.168.100.160 60010 —
To Next Page
