TMC TM7006E User Manual

Compact IP Codec User's Manual
32
Techno Mathematical Co., Ltd.
2140P
(1) Equipment Connection
 Prepare a server with a static IP.
 Connect video output equipment to the encoder HDMI input (or HD-SDI input).
 Connect video input equipment to the decoder HDMI output.
 Connect the LAN ports of the encoder and decoder to the router.
 Turn on the equipment.
Configure IP server information settings on the encoder and decoder.
Table 5-7 Connection via Server Settings
Setting Description Initial Default
ON/OFF Set to ON to use an IP server to connect. OFF
Server IP Address
Sets the IP server IP address. 192.168.100.1
Server Port Sets the IP server port number. (0 to 65535) 62000
CH Sets the channel number. (1 to 9999)
(Sets the encoder's channel number on an
encoder, sets the destination encoder channel
number on a decoder.)
9999
Connection Procedure
