8. EMERGENCY ("ALERT" AND "EVACUATION") BROADCAST
8.1. Emergency Broadcast Equipment
Emergency alert activation input
Emergency evacuation activation input
Emergency stop activation input
External equipment
(ex. fire alarm system)
VM amplifier
(VM-2120/-2240)
Remote microphone
(RM-200M)
Speaker
CONTROL I/O connector
LINK connector
8.2. Keys/Indicators Used for Emergency Broadcast
System management amplifier VM-2120/-2240
Remote microphone RM-200M
Zone indicator
All zone broadcast indicator
All-zone broadcast key
[ALL]
Emergency broadcast indicator [EMERGENCY]
Emergency broadcast indicator
(EMERGENCY)
Emergency broadcast switch
(EMERGENCY)
Talk key (TALK)
Microphone
