TOHATSU M40D2 - Service Data; Tightening Torque

SPECIFICATIONS14
2
Service data
Tightening torque
Model M40/50D2
Item MF EFTO EFO EPTO
Fuel Unleaded Regular Gasoline : R+M/2: 87 or higher RON: 91 or higher
Fuel Tank Capacity L (US gal) 25 (6.6) Separate
Engine Oil Grade Genuine two stroke engine oil or NMMA certified TC-W3 outboard oil
Engine Oil Mixing Ratio Unleaded Gasoline 50 : Genuine 2-stroke Engine Oil 1
Gear Oil
Grade API:GL-5, SAE:80-90
mL (US/Imp.oz) 500 (16.9/17.6)
PTT Fluid -
ATF (Automatic
Transmission
Fluid) Dexron III
-
ATF (Automatic
Transmission
Fluid) Dexron III
Battery (minimum requirements) - 64Ah/5HR, 70Ah/20HR, 512CCA
Spark Plug
M40D2 : NGK B7HS-10 or BR7HS-10
M50D2 : NGK B8HS-10 or BR8HS-10
Spark Plug Gap mm (in) 0.9-1.0 (0.035-0.039)
Gear Oil Plug 4N • m (3 ft • lb, 0.4 kgf • m)
Propeller Nut 35N • m (25 ft • lb, 3.25 kgf • m)
Spark Plug 27N • m (20 ft • lb, 2.7 kgf • m)
PTT Manual Relief Valve 1.8N • m (1.4 ft • lb, 0.18 kgf • m)
