ENGINE OPERATION 45
7
1. Remove the top cowl.
2. Remove starter lock cable from recoil
starter by loosing starter cable lock
screw.
3. Remove the bolts (3pcs) and remove
the recoil starter.
4. Insert the knotted end of the starter
rope into the notch in the flywheel
and wind the rope clockwise around
the flywheel several turns.
5. Tie a loop to other end of the emer-
gency starter rope and attach socket
wrench that is included in the tool kit.
ENOW00860-0
Be sure to keep the harness away from the
rotation parts.
6. Be sure to install the stop switch lock
to the stop switch, and attach the
stop switch lanyard securely to the
operator or to the operator's PFD
(Personal Flotation Device.)
7. Set the shift lever in the Neutral posi-
tion.
ENOF01345-0
ENOF01959-0
CAUTION
ENOF01961-0
ENOF01915-0
