TOHATSU M40D2 User Manual

REMOVING AND CARRYING THE OUTBOARD MOTOR60
8
intended to support the outboard motor
while the boat is docked, beached, etc.
When transporting a boat on a trailer
with the outboard motor attached, dis-
connect the fuel line from the outboard
motor beforehand and keep the out-
board motor in the vertical or on a tran-
som saver bar.
Tiller handle type
While transporting outboard motor
attached to the boat on a trailer, properly
tighten the steering friction bolt to pre-
vent the outboard motor from moving
(page 61).
1. Ground clearance should be provided
sufficiently.
2. Transom saver bar
ENOW00067-0
Do not go under outboard motor tilted up
even if it is supported by support bar, or
accidental fall of outboard motor could lead
to severe personal injury.
WARNING
2
1
ENOF00073-A

TOHATSU M40D2 Specifications

General

Engine Type	2-Cylinder, 2-Stroke
Power Output	40 HP
Displacement	703 cc
Starting System	Manual or Electric
Fuel Type	Gasoline
Fuel System	Carburetor
Gear Ratio	2.08:1
Shaft Length	20 inches
Steering	Tiller or Remote
Oil Type	2-stroke outboard motor oil
Full Throttle Operating Range	5000 - 6000 RPM
